Rotation/revolution mixing-defoaming devices do not have stirring parts that contact the material, but mix and defoam materials in a container using the motion of rotation and revolution. This provides a number of advantages.
Advantages of rotation/revolution mixing-defoaming devices
◇ Not using a mixing rod minimizes cleaning.
◇ Enables both mixing and defoaming in a single device.
◇ Allows only necessary quantity to be mixed by using a suitable size of container.
Advantages of our mixing-defoaming devices
◇ There are no belts to wear out, offering a long product life.
◇ Setup is easy, with simple operation and a memory function.
◇ Adaptors for various containers can be custom-ordered.
◇ We will test-mix/defoam samples to make sure they can be mixed/defoamed by our device.
|
Rotation/Revolution Mixer with High Rotational Speed |
 For OEM supply
| Product Name |
Rotation/Revolution Mixer with High Rotational Speed |
| Model |
(To be announced) |
| Capacity |
300 ml |
| Revolution Speed |
Up to 1000rpm |
| Rotation Speed |
100%, 150%, and 200% of revolution speed
※factory setting |
| Timer Setting |
|
| Memory |
|
| External Dimensions |
303 (W) x 424 (H) x 378 (D) mm (excluding protrusions) |
| Weight |
25kg |
| Power |
AC 100 V ±10%, 50/60 Hz |
| Operating Environment |
5 - 35 ℃, 35 - 85 RH (non-condensing) |
| General Description |
Achieves a maximum revolution-to-rotation ratio of 1:2. This enables the crushing, dispersing, emulsifying, etc. of materials that were difficult or impossible to process in this kind of mixer before.
Food processing becomes quicker:
・Make butter from cream - approx. 1min.
・Impaste fruits, etc. - approx. 30 sec.
|
|
Material Equalizer N300BR (Standard mixing-defoaming device for cups) |
 Material Equalizer N300BR
| Product Name |
Material Equalizer N300BR |
| Model |
ME-N300BR |
| Capacity |
300 ml |
| Maximum loading weight |
370 g (gross) |
| Maximum mixing weight |
240 g (NET) |
| Revolution Speed |
200 - 2200 rpm |
| Rotational Speed |
mixing: 40% of revolution speed / defoaming: 0 rpm |
| Timer Setting |
0 - 99 minutes, settable in one-second increments |
| Memory |
Standard memory: 5 pairs
(one pair = one setting each for mixing and defoaming)
Step memory: 3 sets
(up to 10 steps are programmable per set) |
| Failure Detection Function |
Malrotation, vibrational anomaly, latching failure |
| External Dimensions |
300 (W) x 422 (H) x 390 (D) mm (excluding protrusions) |
| Weight |
Approx. 27 kg |
| Power |
AC 100 V ± 10%, 50/60 Hz |
| Operating Environment |
5 - 35 ℃, 35 - 85 RH (non-condensing) |
|
Material Equalizer N10SR (Mixing-defoaming device for syringes) |
Material Equalizer N10SR
| Product Name |
Material Equalizer N10SR |
| Model |
ME-N10SR |
| Compatible Receptacles |
Syringes (3 ml, 5 ml, 10 ml) |
| Adaptors |
One-to-one option (for 1.7 cc syringe, vial, etc.) |
| Revolution Speed |
200 - 2200 rpm |
| Rotational Speed |
mixing: 25% of revolution speed / defoaming: 0 rpm |
| Timer Setting |
0 - 99 minutes, settable in one-second increments |
| Memory |
Standard memory: 5 pairs
(one pair = one setting each for mixing and defoaming)
Step memory: 3 sets
(up to 10 steps are programmable per set) |
| Failure Detection Function |
Malrotation, vibrational anomaly, latching failure |
| External Dimensions |
300 (W) x 400 (H) x 390 (D) mm (excluding protrusions) |
| Weight |
Approx. 27 kg |
| Power |
AC 100 V ± 10%, 50/60 Hz |
| Operating Environment |
5 - 35 ℃, 35 - 85 RH (non-condensing) |
|
Material Degasser E55SR (Defoaming device for syringes) |
 MD-E55SR
| Product Name |
Material Degasser E55SR
with external vacuum pump connector |
| Model |
MD-E55SR |
| Compatible Receptacles |
Syringes (30 ml, 50 ml, 55 ml) |
| Revolution Speed |
1000, 1600, 2500 rpm |
| Timer Setting |
0 - 10 minutes |
| External Dimensions |
310 (W) x 470 (H) x 375 (D) mm (excluding protrusions) |
| Weight |
16 kg |
| Power |
AC 100 V ± 10%, 50/60 Hz |
| Operating Environment |
5 - 35 ℃, 35 - 85 RH (non-condensing) |
|
gako unguator PRO (blade-type mixer) |
 gako unguator PRO (blade-type mixer)
| Product Name |
gako unguator PRO |
| Model |
gako unguator PRO |
| Containers to be used |
gako unguator jars
15ml - 2000ml |
| Revolution Speed |
300 - 2400rpm |
| Mixing programs |
Standard & Customized programs |
| External Dimensions |
293 (W) x 670 (H) x 339 (D) mm (excluding protrusions) |
| Weight |
16.5kg |
| Power |
AC 100-115 V / 220-240 V |
| Operating Environment |
5 - 30 ℃, up to 85 RH (non-condensing) |
| Communication |
USBx4, RS-232x3, RJ-45x1 |
| Manufacturer |
gako international GmbH (Germany) |
|
| |
